complex 3D illustration fuel station

Esto es lo que buscaba un negocio en Morocco en su graphic design

Make a technical graphic 3D illustration using the "base image" and using as inspirations for the modifications the "total system" image.
The fuel dispensers should be equipped under them by dispenser sumps use as model the image "dispenser.png" .
The tanks should be equipped in top of them by tank sumps use as model the image "tank.jpg".
2 Pipes Black and red per tank should connect the tanks sumps to the dispenser sumps.
1 pipe to connect each tank to the vent area
1 pipe to connect each tank to the filling area
Use instructions file + total system file to help understand what is needed. Leer más
